Product Documentation

Document	Pages	Notes
External Photos	3
Internal Photos	3
User Manual	24

Product

Parameter	Value	Description
Form Factor	Handheld	The radio is designed to be held in one hand while in use.
Type	Transceiver	The radio can receive and transmit signals.
Operating Temperature	-20 to 60 °C	The range of temperatures in which the product is designed to be operated.

Tuning System

Parameter	Value	Description
Channel Capacity	30 max	The number of memory channels that can be programmed into the radio.
Channel Bandwidths	12.5 kHz	The radio's tuning system supports channel spacing of 12.5 kHz.
	20 kHz	The radio's tuning system supports channel spacing of 20 kHz.
Repeater Capable	Yes	Memory channels can have different transmit and receive frequencies, facilitating the use of radio repeaters.

Signaling System

Parameter	Value	Description
CTCSS Tones	50	The number of distinct CTCSS tones supported by the radio.
DCS Codes	232	The number of distinct DCS codes supported by the radio.

Audio System

Parameter	Value	Description
Voice Prompts	Yes

Receiver

Parameter	Conditions	Value	Description
	Tuning System
	Channel Bandwidth
Personal Bands		FRS	Family Radio Service (462.550 - 467.7125 MHz)
		GMRS	General Mobile Radio Service (462.550 - 467.725 MHz)
Sensitivity Threshold	12.5 kHz	0.3 µV max	The magnitude of the smallest RF signal that a receiver can detect.
	20 kHz	0.25 µV max
Adjacent Channel Selectivity		65 dB min	The ability of a receiver to discriminate between a desired signal and an undesired signal in an adjacent channel.
Spurious Rejection		55 dB min	The ratio of a receiver's response to a signal at a desired frequency and its response to signals at other frequencies that cause a response.
Intermodulation Rejection		60 dB min	The ability of a receiver to reject intermodulation products produced by the mixing of two or more signals at the input to the receiver.
Audio Distortion		5 % max
Monitor Function		Yes	The radio allows the user to manually open the squelch.

Transmitter

Parameter	Conditions	Value	Description
	Tuning System
	Channel Bandwidth
Personal Band		GMRS	General Mobile Radio Service (462.550 - 467.725 MHz)
Frequency Drift		2.5 ppm	The amount that a transmitter's frequency varies from its nominal value.
Output Power		5 W max	The maximum RF power that a transmitter can produce, as reported by the manufacturer in product documentation.
Measured Power		4.47 W max	Actual output power measured by a telecommunication certification body (TCB) and reported to the Federal Communications Commission.
Audio Distortion		5 % max
Emission Types	12.5 kHz	11K0F3E	11 kHz occupied bandwidth, FM analog voice
	20 kHz	16K0F3E	16 kHz occupied bandwidth, FM analog voice
VOX		Yes
Timeout Timer		Yes	Indicates that a radio is capable of limiting the length of each transmission.

Channel Selector

Parameter	Value	Description
Location	Top	The channel selector is located on the top of the radio.
Type	Rotary Knob	The setting can be adjusted by rotating a round knob.

Volume Control

Parameter	Value	Description
Location	Top	The volume control is located on the top of the radio.
Type	Rotary Knob	The setting can be adjusted by rotating a round knob.

Squelch Control

Parameter	Value	Description
Location	Menu	The squelch level can be adjusted through the radio's menu system.

Internal Speaker

Parameter	Value	Description
Location	Front	The internal speaker is located behind the front panel of the radio.

Microphone Port

Parameter	Value	Description
Location	Right Side	The microphone ports is located on the right side of the radio.

Speaker Port

Parameter	Value	Description
Location	Right Side	The speaker port is located on the right side of the radio.

Headset Port

Parameter	Value	Description
Location	Right Side	The headset port is located on the right side of the radio.

Programming Port

Parameter	Value	Description
Location	Right Side	The programming port is located on the right side of the radio.

Antenna Port

Parameter	Value	Description
Location	Top	The antenna port is located on top of the radio.
Connector Type	SMA-Female	SMA Female

Battery

Parameter	Value	Description
Charge Capacity	1400 mAh	The amount of charge stored in a fully-charged battery.
Energy Capacity	10.36 Wh	The amount of energy stored in a fully-charged battery.
Type	Li-Ion	Lithium Ferrous Phosphate (LiFePO4)
Voltage	7.4 V	The nominal voltage of a battery.
Removable		Battery is removable, allowing a discharged battery to be quickly replaced with a fresh one.
Low Voltage Alert	Yes	The device alerts the user when the battery voltage falls below a threshold.
Charging Method	Drop-In
