Product Documentation

Document	Pages	Notes
MD-UV380 - External Photos
MD-UV380 - Internal Photos
MD-UV380 - User Manual, Part 1
MD-UV380 - User Manual, Part 2

Product

Parameter	Value	Description
Form Factor	Handheld	The radio is designed to be held in one hand while in use.
Type	Transceiver	The radio can receive and transmit signals.
Width	61 mm	The distance between the left and right surfaces of the main body of the radio, excluding protrusions.
Height	131 mm	The distance between the top and bottom surfaces of the main body of the radio, excluding protrusions.
Depth	36 mm	The distance between the front and rear surfaces of the main body of the radio, excluding protrusions.
Weight	258 g	The mass of the main body of the radio, including the removable battery or removable front panel.
Operating Temperature	-10 to 40 °C	The range of temperatures in which the product is designed to be operated.

Tuning System

Parameter	Value	Description
Channel Capacity	3000 max	The number of memory channels that can be programmed into the radio.
Channel Bandwidth	12.5 kHz	The radio's tuning system supports channel spacing of 12.5 kHz.
Repeater Capable	Yes	Memory channels can have different transmit and receive frequencies, facilitating the use of radio repeaters.
Talkaround	Yes	Sets the transmit frequency equal to the receive frequency when using a repeater channel.
Zone Capacity	250 max	The maximum number of zones that the radio can store.
Zone Channel Capacity	16 max	The maximum number of channels per zone.
Digital Protocols	ETSI TS 102 361-1	DMR Air Interface (AI) Protocol
	ETSI TS 102 361-2	DMR Voice and Generic Services
	ETSI TS 102 361-3	DMR Data Protocol

Signaling System

Parameter	Value	Description
Remote Actions	Stun	Temporarily disables the receiving radio until it is revived.
	Kill	Permanently disables the receiving radio until a technician reprograms it.
	Revive	Restores a stunned radio to normal functionality.
Selective Call	Yes	Enables one radio user to initiate a conversation with another specific user.
Group Call	Yes	Enables a radio user to initiate a conversation with a predetermined group of radio users. All users can hear one another during the conversation.
All Call	Yes	The radio can page every user on the same channel.
Emergency Call	Yes	Sends out a distress call to other radios. May also place the radio in hands-free mode to so the user can describe his situation without needing to continually press the PTT button.
Call Logging	Yes	The radio can keep a record of the calls that were transmitted, received, and not answered.
Lone Worker	Yes	Alerts coworkers when a lone worker does not respond to periodic prompts to confirm that he is safe.

Audio System

Parameter	Value	Description
Silent Mode	Yes	The radio emits no beeps or other sounds apart from received audio.
Output Power	1 W max
Recording Capacity	8 h max
Vocoder Type	AMBE+2

Messaging System

Parameter	Value	Description
Contact Capacity	10000 max	The maximum number of contacts that the radio can store.
SMS Messaging	Yes
Message Length	144 max	The maximum length of a text message sent or received by the radio.
Canned Message Count	50 max	The number of pre-programmed messages that the radio can store.
Log Capacity	50 max	The maximum number of recently sent messages that the radio can store.

Receiver

Parameter	Conditions				Value	Description
	Tuning System		Receiver
	Channel Bandwidth	Operating Mode	SINAD	Bit Error Rate
LMR Bands					VHF	Land mobile VHF high band (150 - 174 MHz)
					UHF	Land mobile UHF band (450 - 470 MHz)
Operating Frequency					136 to 174 MHz	The range of frequencies that can be tuned by the receiver.
					400 to 480 MHz
Sensitivity Threshold		DMR		5	0.25 µV max	The magnitude of the smallest RF signal that a receiver can detect.
		FM	12 dB		0.2 µV max
Adjacent Channel Selectivity	12.5 kHz				-60 dB min	The ability of a receiver to discriminate between a desired signal and an undesired signal in an adjacent channel.
Bit Error Rate					5 % max
Spurious Rejection					70 dB min	The ratio of a receiver's response to a signal at a desired frequency and its response to signals at other frequencies that cause a response.
Intermodulation Rejection					60 dB min	The ability of a receiver to reject intermodulation products produced by the mixing of two or more signals at the input to the receiver.
FM Hum and Noise	12.5 kHz				-40 dB max	The frequency modulation present on an unmodulated carrier.
	25 kHz				-45 dB max
Audio Distortion					5 % max
Audio Response					-3 to 1 dB	The degree of precision with which the audio signal level of a receiver responds to the frequency deviation of an FM signal.
Monitor Function					Yes	The radio allows the user to manually open the squelch.

Transmitter

Parameter	Conditions		Value	Description
	Tuning System
	Channel Bandwidth	Operating Mode
Land Mobile Bands			VHF	Land mobile VHF high band (150 - 174 MHz)
			UHF	Land mobile UHF band (450 - 470 MHz)
Operating Frequency			136 to 174 MHz
			400 to 480 MHz
Frequency Drift			1 ppm	The amount that a transmitter's frequency varies from its nominal value.
Output Power			5 W max	The maximum RF power that a transmitter can produce, as reported by the manufacturer in product documentation.
Spurious Emissions			-36 dB max	Emission on a frequency or frequencies which are outside the necessary bandwidth.
FM Hum and Noise			-40 dB max	The frequency modulation present on an unmodulated carrier.
Adjacent Channel Power			-60 dB max
Audio Response			-3 to 1 dB	The degree of precision with which the frequency deviation of a transmitter responds to a designated audio frequency signal level.
Emission Types	12.5 kHz	DMR	7K60FXD	7.6 kHz occupied bandwidth, 2-slot DMR TDMA data
	12.5 kHz	DMR	7K60FXE	7.6 kHz occupied bandwidth, 2-slot DMR TDMA voice
	12.5 kHz	FM	11K0F3E	11 kHz occupied bandwidth, FM analog voice
	25 kHz	FM	16K0F3E	16 kHz occupied bandwidth, FM analog voice
VOX			Yes
Timeout Timer			Yes	Indicates that a radio is capable of limiting the length of each transmission.
Deviation	12.5 kHz		2.5 kHz

Channel Selector

Parameter	Value	Description
Location	Top	The channel selector is located on the top of the radio.
Type	Rotary Knob	The setting can be adjusted by rotating a round knob.

Volume Control

Parameter	Value	Description
Location	Top	The volume control is located on the top of the radio.
Type	Rotary Knob	The setting can be adjusted by rotating a round knob.

Squelch Control

Parameter	Value	Description
Location	Menu	The squelch level can be adjusted through the radio's menu system.

Keypad

Parameter	Value	Description
Location	Front	The keypad is located on the front panel of the radio.
Lockable	Yes	The keypad can be configured in a way that disables the function of most keys.
Audible	Yes	The keypad can be configured to emit a sound each time that a key is pressed.

Display

Parameter	Value	Description
Type	LCD	Liquid Crystal Display with Fluorescent Backlighting
Backlit	Yes	The display device is illuminated for better readability in poor lighting conditions.

Internal Speaker

Parameter	Value	Description
Location	Front	The internal speaker is located behind the front panel of the radio.

Microphone Port

Parameter	Value	Description
Location	Right Side	The microphone ports is located on the right side of the radio.

Speaker Port

Parameter	Value	Description
Location	Right Side	The speaker port is located on the right side of the radio.

Headset Port

Parameter	Value	Description
Location	Right Side	The headset port is located on the right side of the radio.

Programming Port

Parameter	Value	Description
Location	Right Side	The programming port is located on the right side of the radio.

Antenna Port

Parameter	Value	Description
Location	Top	The antenna port is located on top of the radio.
Connector Type	SMA-Female	SMA Female
Impedance	50 Ω

Battery

Parameter	Value	Description
Charge Capacity	2000 mAh	The amount of charge stored in a fully-charged battery.
Energy Capacity	14.8 Wh	The amount of energy stored in a fully-charged battery.
Type	Li-Ion	Lithium Ferrous Phosphate (LiFePO4)
Voltage	7.4 V	The nominal voltage of a battery.
Voltage Indicator	Yes	The device provides a visible or audible indication of the battery voltage.
Removable	Yes	Battery is removable, allowing a discharged battery to be quickly replaced with a fresh one.
Charging Method	Drop-In
