Product Documentation

Document	Pages	Notes
Datasheet	2

Product

Parameter	Value	Description
Operating Frequency	460 to 470 MHz
Type	Mobile Whip
Center Frequency	465 MHz
Bandwidth	10 MHz	The frequency range occupied by a modulated carrier.
Length	311 mm
Personal Band	GMRS	General Mobile Radio Service (462.550 - 467.725 MHz)
Land Mobile Band	UHF	Land mobile UHF band (450 - 470 MHz)

Signal Propagation

Parameter	Value	Description
Power	150 W max	The input power limit of an antenna.
Gain	4.5 dBi	The ability of an antenna to radiate RF energy in a specific direction.
ERP	257.686 W max	Effective Radiated Power

Base

Parameter	Value	Description
Type	NMO	The antenna base is designed to screw into an NMO mount that is affixed to a horizontal surface.

Feedpoint

Parameter	Value	Description
Impedance	50 Ω	The effective resistance of an antenna to alternating current at a specific frequency due to the combined effects of ohmic resistance, inductance, and capacitance.
