Product Documentation

Document	Pages	Notes
Manufacturer's Product Page	1
User Manual	12

Product

Parameter	Value	Description
Style	Rigid
Frame Color	Black
Shape	Rectangular
Height	1724 mm	The vertical distance between the top and bottom surfaces of an item that is placed in its conventional orientation.
Width	1134 mm	The horizontal distance between the left and right surfaces of an item that is placed in its conventional orientation.
Depth	35 mm	The horizontal distance between the front and rear surfaces of an item that is placed in its conventional orientation.
Area	1.955 m²
Weight	27.62 kg	The weight of the item.
Wind Load	2400 Pa max
Snow Load	2400 Pa max
Application Class	Class A	The module operates at greater than 50 VDC or 240 W and it can safely be installed in locations accessible by the public.

Cell

Parameter	Value	Description
Count	108
Type	Mono Si	The cells are made of Monocrystalline Silicon.
Bus Bars	10
Attribute	Half-Cut

Power

Parameter	Value	Description
Rated Power at STC	400 W	Output Power at Maximum Power Point under Standard Test Conditions
Power Density at STC	204.604 W/m²	Power Density under Standard Test Conditions
Efficiency at STC	20.46 %	Module Efficiency under Standard Test Conditions

Voltage

Parameter	Value	Description
Rated Voltage at STC	31.01 V	Output Voltage at Maximum Power Point under Standard Test Conditions
Open Circuit Voltage at STC	37.07 V max	Open Circuit Voltage under Standard Test Conditions
System Voltage	1000 V max

Current

Parameter	Value	Description
Rated Current at STC	12.9 A	Output Current at Maximum Power Point under Standard Test Conditions
Short Circuit Current at STC	13.79 A max	Short Circuit Voltage under Standard Test Conditions
System Fuse Rating	25 A max

Temperature

Parameter	Value	Description
Operating Temperature	-40 to 185 °F	The range of temperatures in which the product is designed to be operated.

Junction Box

Parameter	Value	Description
Solid Ingress Protection Level	IP6x	The product is dust-tight.
Liquid Ingress Protection Level	IPx7	The product is protected against the effects of temporary immersion in water.

Positive Lead

Parameter	Value	Description
Wire Diameter	12 AWG (4 mm²)
Wire Length	4.9 ft
Connector Type	MC4

Negative Lead

Parameter	Value	Description
Wire Diameter	12 AWG (4 mm²)
Wire Length	4.9 ft
Connector Type	MC4
